Product

Features:

ITE and Medical applications

SNP-F50X (500W), SNP-F60X (600W),

SNP-F80X (800W), SNP-FA0X (1000W)

Output Specifications:
Rated Power Model No. OUTPUT Size WxLxH
500W SNP-F507 +12V/41.60A 4.5"x7.5"x1.66"
500W SNP-F509 +24V/20.80A 4.5"x7.5"x1.66"
500W SNP-F50T +48V/10.40A 4.5"x7.5"x1.66"
500W SNP-F50H +63V/8A 4.5"x7.5"x1.66"
600W SNP-F607 +12V/45.80A 5"x10.83"x2.95"
600W SNP-F609 +24V/25.00A 5"x10.83"x2.95"
600W SNP-F60J +36V/16.67A 5"x10.83"x2.95"
600W SNP-F60T +48V/12.50A 5"x10.83"x2.95"
800W SNP-F809 +24V/33.30A 4.5"x9.5"x1.66"
800W SNP-F80T +48V/16.66A 4.5"x9.5"x1.66"
800W SNP-F80H +63V/12.70A 4.5"x9.5"x1.66"
1000W SNP-FA09 +24V/41.66A 5.7"x9.5"x1.89"
1000W SNP-FA0T +48V/20.83A 5.7"x9.5"x1.89"
1000W SNP-FA0H +63V/15.87A 5.7"x9.5"x1.89"
  Skynet PowerSwitching Power SupplyPower Supply for ITE and Medical applications
